The Same Bridge, the Parity Way — and the Bill

In ISMP Bridging with Satsuma we bridged two satsuma chains with ISMP: on-chain GRANDPA light clients, state proofs, an untrusted courier. That’s not the only implementation of the idea. Parity has shipped it for years as parity-bridges-common — the stack that moves value between Polkadot and Kusama today.

So we built the same bridge again. Same two 500ms chains, same burn-prove-mint feature (literally the same pallet — pallet-xtransfer grew a second extrinsic), same untrusted relayer role. Different machinery. This is the head-to-head.

Same idea, different shape

Both stacks do exactly two things on-chain: verify the peer’s GRANDPA finality, then verify state proofs against the finalized root. The differences are all in the plumbing:

• pallet-bridge-grandpa is a header chain: relayers feed it the peer’s finalized headers with justifications (submit_finality_proof_ex), it keeps the verified head. Justifications on our single-validator chains are a tidy 178 bytes.
• pallet-bridge-messages adds ordered lanes: outbound messages get consecutive nonces, deliveries carry storage proofs of the outbound queue (~1 KB per batch), inbound tracking enforces exactly-once, in-order dispatch, and a third transaction type — the confirmation — proves delivery back to the source so it can prune its queue.

Where ISMP gives you a request/response protocol with timeouts and refunds, lanes give you a conveyor belt: strict ordering, explicit confirmation, nothing else. Our transfer pallet needed a custom dispatcher on the receiving side (decode payload → mint) — ~130 lines of runtime config in total.

The demo

Same choreography as before: two sovereign chains, sudo seeds each side’s light client with the other’s authority set, the relayer starts working, and 5 UNIT crosses A→B and B→A — verified, minted, balanced. The difference you can see is step 6: the bill. Every relayer action is a signed transaction with a fee:

A demo run’s total came to ~0.025 UNIT of relayer spend — versus zero for ISMP, whose datagrams ride in unsigned, proof-validated extrinsics admitted by the transaction pool on the strength of their proofs alone. Production Parity-stack deployments bolt on pallet-bridge-relayers to reimburse relayers from bridge fees; between two chains we operate ourselves, the “bill” is money moving between our own pockets — but it sizes the subsidy honestly.

The measured head-to-head

Ten transfers each way, same machine, same block time:

The latency gap is plumbing, not cryptography: our lane relayer needs two sequential transactions (finality, then delivery) where the ISMP relayer ships consensus + request in one pass. Both bridges’ true heartbeat is the justification cadence — we generate one every 4 blocks (2 s).

Which one should a satsuma-class chain use?

ISMP direct peering is our default. Faster in practice, 3x smaller message proofs, request/response + timeout/refund semantics that map straight onto product features, no funded relayer account required — and the same pallets upgrade into a Hyperbridge connection when we want reach beyond chains we operate.

The Parity stack is the conservative pick when strict per-lane ordering is a hard requirement, when “this exact code runs Polkadot↔Kusama” is the sentence your auditor wants to read, or when you need a crates.io-only supply chain (Polytope’s aggressive version yanking made us pin git tags and seed a lockfile — real, if minor, operational friction). Its relayer was also the easiest code of the whole study: 208 lines of JavaScript against plain RPC.

Either way, the conclusion of the pair of posts stands: two sovereign chains can hold each other to cryptographic truth — no custodian, no committee, no favors. The technology is here, it’s open source, and it runs at satsuma’s block time.

Caveats

Same list as the ISMP post — single-validator chains (178 B justifications grow with the authority set), loopback latency, no relayer incentive layer. Plus two stack-specific ones: message lanes must be opened at genesis (there’s no extrinsic; production uses pallet-xcm-bridge-hub), and our JS relayer is a prototype — the production substrate-relay binary exists but is built around Parity’s own chain pairs.
